DBMFL-200W
| Specification | Standard | Instruments | Actual |
|---|---|---|---|
| Input Voltage | AC180-265V | Light Source Analysis System | 240 V |
| Frequency Range | 50-60Hz | Light Source Analysis System | 50 Hz |
| Power Efficiency | >87% | - | - |
| Power Factor | PF > 0.9 | Light Source Analysis System | 0.992 |
| Power Consumption | 200W ±10% | Light Source Analysis System | P = 190.8W |
| LED Luminous Efficiency | 90~110 LM/W | - | 97.4 LM/W |
| Lamp's Efficiency | >89% | - | - |
| Base | Aluminium Casting | - | - |
| Luminous Flux | 20000 LM ±10% | Light Source Analysis System | 18142 LM |
| Color Temperature |
WW: 2900-3100K DW: 3900-4300K CW: 5700-6800K |
Light Source Analysis System | Tc = 7086K |
| CRI | Ra>80 | Light Source Analysis System | Ra = 82.6 |
| Beam Angle | 90° | - | OK |
| LED Quantity | 290 PCS (1W SMD2835) | - | OK |
| LED Brand | SANAN | - | OK |
| Illuminance Uniformity | >0.6 | - | OK |
| LED Junction Temperature | ≤80°C | - | OK |
| Working Temperature | -20°C ~ 40°C | - | OK |
| Storage Temperature | -20°C ~ 65°C | - | OK |
| Lifespan | 2 Years | - | OK |
| IP Grade | IP65 | - | OK |
| Dimension | 280 × 378 × 25 mm | Measuring Tape and Vernier Caliper | 280 × 378 × 25 mm |
| Net Weight | 1580 g | - | - |
| Gross Weight | 1580 g | - | - |
| Packing Size (1PC/Box) | 280 × 378 × 25 mm | - | - |
| Carton Size | 40.7 × 19.5 × 31.8 cm | - | - |
| Qty/CTN | 5 PCS | - | - |
| Certificates | BIS | - | - |
| Warranty | 2 Years | - | - |
